DCN: 140-02302-01 Page 9
Installer Settings Summary
Setting Range Default
Display Lock Y or N N Locks out front buttons
Service Mode Submenu
Test Mode Y or N N Reduces delays for testing
System Settings Submenu
Mechanical Settings Submenu
Sys Type Std or HP Std
Fan Type Gas or Elec Gas
C/O Type w/Heat or w/Cool w/Cool
2
Stage Heat Y or N N
Aux Heat Y or N Y
2
Stage Cool Y or N N
H/C Delta 3 – 15 deg 3
Heat Delta Stage 1 On 1 – 8 1
Heat Delta Stage 1 Off 0 – 8 0
Heat Delta Stage 2 On 1 – 8 2
Heat Delta Stage 2 Off 0 – 8 0
Heat Delta Stage 3 On 1 – 8 3
Heat Delta Stage 3 Off 0 – 8 0
Cool Delta Stage 1 On 1 – 8 1
Cool Delta Stage 1 Off 0 – 8 0
Cool Delta Stage 2 On 1 – 8 2
Cool Delta Stage 2 Off 0 – 8 0
Max Heat SP 40-109F (4-42C) 90F
Min Cool SP 44-113F (6-45C) 60F
Min Run Time 1-9 min 3
Min Off Time 1-9 min 5
Temp Response 1-6 2
Remote Sensors Submenu
RS1 Type (curve type) Curve A, Type 2, Type 3 Type 3
RS2 Type (curve type) Curve A, Type 2, Type 3 Type 3
RS2 Location (Indoors or Outdoors) In, Out In
Restore Defaults (factory defaults) Yes or No No Exit = no
USER SETTINGS
Filter Service Submenu
Service Interval Disabled, 100-4000 hrs 300
Maint Service Submenu
Maint Interval Disabled, 100-4000 hrs 3000
Screen Timeout (to minimized screen) 0, 20-120 sec 0 0 = off , will not timeout
RH Setpoint 40-70% 50%
F/C Settings F or C F
Sensor Calibration Submenu Internal -7 to +7 0
Backlite/Display Submenu
Backlight Timeout 0, 20-120 0 0 = backlite off
Backlight On Brightness 0-100% 100%
Backlight Off Brightness 0-100% 0%
Contrast 0-20 12
DCN: 140-02302-01 Page 10
Connection to Mi-Wi Network
This thermostat is designed to connect to the SiteSage Gateway using the Mi-Wi wireless
protocol. The Gateway will automatically detect a thermostat and initiate the connection.
See the SiteSage Installation Manual for additional details.
It is critical that the MAC address of the thermostat is mapped to the
name of the zone served by the thermostat. The Thermostat MAC
address can be found in the Mi-Wi Network menu option (the last
one in the list of options shown when the Menu Button is selected.
