WE STRIVE FOR PERFECT, ALTHOUGH IT ’S NOT ALWAYS POSSIBLE, WE NEVER LEAVE A RIDER BEHIND.
HANDLEBAR
STEM BOLT
Line up the stem, frame, and front wheel, then tighten the handlebar
stem bolt.
Seat Post
LOCK NUT CAP
ST1 STEM
ST2 LOCK NUT/
HEAD TUBE
15
Place the lock nut cap in between ST1 and ST2.
HANDLEBARLOCK NUT CAP
Straightening the stem, frame, and front
wheel will ensure that your handlebars
and wheel are properly aligned.
NOTE
