8
Names of each part
Cold water lamp
Hot water lamp
Button of hot water safety
Button of High Temperature
Button of UV care Water tap
Button of UV care Water tank
Constant button
Water intake tap
Water intake button
The place for receiving water
Lower panel
Top cover
Front panel
Cold water switch
Hot water switch
The slot of water supply
Connection of water drain
Connection of cooking valve
Connection of drainage
Cord of power connection
Names of each part
Model WPU-B300F/B400F
[Stand type]
<Front> <Back>
WPU-B300C_EN-MY.indd 8 2018-09-28  5:33:23
