SKF ConCentra - Page 34

SKF ConCentra ball bearing units with plummer block housing, for metric shafts
d 25 – 60 mm
SKF ConCentra ball bearing units with plummer block housing, for metric shafts
d 25 – 50 mm
d
Da
A
2
3,2
N
HJ
H14
H11
s
1
B
G
T L
A
1
Shaft
diameter
Bearing unit Mass Designation
Dimensions Bearing unit
d A
1
A
2
B D
a
H J L N G s
1
T
mm mm
kg
–
25 30,0 12 33,0 63,5 124,0 99,0 70 11,5 M10 21,0 40,0 0,65 FYTB 25 LF
30 32,5 13 37,0 76,2 141,5 116,5 83 11,5 M10 23,0 43,0 0,95 FYTB 30 LF
35 34,5 13 39,5 88,9 156,0 130,0 96 14 M12 24,3 45,3 1,28 FYTB 35 LF
40 38,5 14 42,9 88,9 171,5 143,5 102 14 M12 25,9 49,9 1,69 FYTB 40 LF
45 39,0 14 44,0 98,4 178,5 148,5 111 16 M14 26,5 50,5 1,87 FYTB 45 LF
50 43,0 15 46,0 101,6 189,0 157,0 116 18 M16 27,5 55,5 2,22 FYTB 50 LF
