Type: W1G with signal smoothing
(max. 24 VDC) for NLGI Grade 2 greases
Technical data
Fill level monitoring
Function .............floating contact
Form of contact .......
Changeover
Switching capacity ......max. 60 W
Switching voltage ......max. 30 VDC
Plug-in connection DIN EN 60947/IEC 947
Connection diagram ....7-pin round plug
1
)
1) Socket-see AccessoriesPage 28
The connection is established via a 4-pin cir-
cular connector on the bottom of the pump.
The W1G with signal smoothing is standard in
the design:
W1-smooth with output signal:
The following functions are integrated into the
KFG pump unit with signal smoothing:
Ability to isolate supply voltage poten-
pump voltage.
Fill level information can also be que-
ried during the interval time.
Reverse voltage protection in pump
feed line planned.
Optional time-out periods.
The individual functions are implemented us-
ing internal jumpers according to the custom-
Assembly instructions
KFG
