Section 04 ENGINE
Sub-Section 02 (454, 583 AND 670 ENGINE TYPES)
04-02-11
10,11, Pipe Sealant and Angular Tube
Apply pipe sealant (P / N 413 7023 00) on threads
prior to assembly angular tube.
12, Crankcase Stud
At assembly on crankcase, apply medium
strength threadlocker (P / N 413 7030 00) on stud
threads.
13, Crankcase / Engine Bracket Nut
Torque the crankcase / engine bracket nut to 38
N•m (28 lbf•ft).
To install magneto, refer to CDI MAGNETO 04-05.

Ski-Doo Mach Z Specifications

General

Engine Displacement	899 cc
Horsepower	180 hp
Track Length	137 inches
Track Width	15 inches
Cylinders	2
Engine Stroke	2-Stroke
Cooling	Liquid
Fuel System	Electronic Fuel Injection (EFI)
Seating Capacity	1
Fuel Capacity	10.6 gallons
Brake System	Hydraulic
