Section 01 SERVICE TOOLS AND SERVICE PRODUCTS
Sub-Section 01 (SERVICE TOOLS)
ENGINE (Optional Service Tools)
The following tools are highly recommended to optimize your basic tool kit and reduce repair time.
1-2 Crankshaft bearing
~
puller with screw
(p/ N 4208762 98)
H
2
1+2
.——————————
5,6,7 —Q
3—
l?!
4—
8—
e
9—
e
10,11 —
GB
AOOC3L4
APPLICATION
247, 277,377,443, 503, 582
an
583 engines.
1-2 Crankshaft bearing ~
puller with screw
(p/ N 4208776 35)
NEW
H
4 4
1+2
.——————————
6—f ~ 5,7
Q
9,12
@
— 10,11,13
A01BW4
APPLICATION
All, including 454, 494, 670, 59
and 779 engines.
Tools to be used with crankshaft bearing pullers N (P/N 4208762 98) and
~ (p/N 4208776 35).
-.
u
2- Bolt (M16 X 1.5 X 150)
(p/ N 4209407 55)
m
:
Use with both ~ or ❑ pullers.
3- Screw M8 x 40 (4)
(P/ N 420 840681)
m
●
❑ puller MAG side, ❑ puller MAG and PTO side.
4- Screw M8 x 70 (4) (P/ N 420 841201)
❑ Puller only, PTO side.
m
● C
5- Crankshaft protector
(p/ N 4209768 90)
m
● 0
247 engine.
6- Crankshaft protector PTO
(P/ N 4208765 52)
m
●
~ or ❑ Puller; all engines except 247.
7- Crankshaft protector MAG
(p/ N 4208765 57)
m
A
~ or ❑ puller; all engines except 247,
8- Distance ring PTO
(p/ N 4208765 69)
m
~ puller; 377,443,503,582 and 583 engines,
9- Puller ring
(P/ N 4209774 90)
m
Use with half rings (P/ N 420977475 or 4202760 25).
10- Half ring (2)
(p/ N 4209774 75)
m
●
~ or ❑ puller; for 72 mm O.D. bearings.
11- Half ring
(p/ N 4202760 25)
m
:
~ or ❑ Puller; for 62 mm O.D. bearings.
12- Puller ring
(p/ N 4209774 94)
m
For half rings (P/ N 4209774 79).
13- Half ring
(P/ N 4209774 79)
m
~ puller only; 80 mm O.D. bearings,
01-01-4

Ski-Doo Mach Z Specifications

General

Engine Displacement	899 cc
Horsepower	180 hp
Track Length	137 inches
Track Width	15 inches
Cylinders	2
Engine Stroke	2-Stroke
Cooling	Liquid
Fuel System	Electronic Fuel Injection (EFI)
Seating Capacity	1
Fuel Capacity	10.6 gallons
Brake System	Hydraulic
