Section 01 SERVICE TOOLS AND SERVICE PRODUCTS
Sub-Section 01 (SERVICE TOOLS)
RAVE movement
m
●
indicator
(p/ N 8617258 00)
A18B014
APPLICATION
All RAVE equipped engines.
Air pressure gauge,
0-200 inch of water
m
(p/ N 5290104 ()())
Q
80 ~ 120
60
0 e MO
/
40
160
m
n H20
180
200
=
. .
W
n]
A18B034
APPLICATION
For pressure testing gauge.
ENGINE (Optional Service Tools)
Dial indicator
m
I
(TDC gauge)
(p/ N 2950001 43)
AOOB2E4
APPLICATION
All engines.
Seal protector sleeve
A)(p/N4208769
80)
(for 10 mm shaft)
m
B) (p / N 4208764 90)
(for 12 mm shaft)
m
D
AOOCOD4
APPLICATION
467, 582, 583 and 670 engines.
Magneto puller
m
(p/ N 4209762 35)
AOOC1A4
APPLICATION
247 engine.
Injection pump gear
m
A
holder
(p/ N 4208766 95)
0)
AOOB314
APPLICATION
253, 377, 447 and 503
engines.
Injection pump gear
m
holder
(P/ N 4202779 05)
AOOC164
APPLICATION
467, 494, 536, 537, 582, 583,
643, 670 and 779 engines.
Bombardier magneto
m
●
tester
(p/ N419 0033
00)
@o
&
IGNITION TESTER ~ w ~
a
m
Reset
m
@ ‘“6°’ a“
10 90
0
@
10I
Low
W+ I
&a y
AOOC1K4
APPLICATION
All engines.

Ski-Doo Mach Z Specifications

General

Engine Displacement	899 cc
Horsepower	180 hp
Track Length	137 inches
Track Width	15 inches
Cylinders	2
Engine Stroke	2-Stroke
Cooling	Liquid
Fuel System	Electronic Fuel Injection (EFI)
Seating Capacity	1
Fuel Capacity	10.6 gallons
Brake System	Hydraulic
