Ski-Doo Mach Z User Manual

Section 06 ELECTRICAL
Sub-Section 01 (WIRING DIAGRAMS)
06-01-1
WIRING DIAGRAMS 1
hal. = halogen
CHART CODES
Wiring Color Code
The first color of a wire is the main color, second
color is the stripe.
Example : YL / BK is a YELLOW wire with a
BLACK stripe.
MODEL
WIRING
DIAGRAM
PAGE
HEADLIGHT
(watt)
TAILLIGHT
(watt)
ELECTRICAL
SYSTEM
OUTPUT
(watt)
MX Z 440 / 583 / 670 Annex 1 60 / 55 hal. 8 / 27 220
Summit 583 / 670 Annex 2 60 / 55 hal. 8 / 27 220
Formula Z Annex 3 60 / 55 hal. 8 / 27 220
Formula SS Annex 4 60 / 55 hal. 8 / 27 220
Formula III / III LT and
Mach Z / Z LT
Annex 5 60 / 55 hal. 8 / 27 220
Skandic WT Annex 6 60 / 55 hal. 8 / 27 240
COLOR CODE
BK – BLACK
WH – WHITE
RD – RED
BL – BLUE
YL – YELLOW
GN – GREEN
GY – GREY
VI – VIOLET
OR – ORANGE
BR – BROWN

Ski-Doo Mach Z Specifications

General

Engine Displacement	899 cc
Horsepower	180 hp
Track Length	137 inches
Track Width	15 inches
Cylinders	2
Engine Stroke	2-Stroke
Cooling	Liquid
Fuel System	Electronic Fuel Injection (EFI)
Seating Capacity	1
Fuel Capacity	10.6 gallons
Brake System	Hydraulic
