1. Black / Red
2. Red
All Engines
3. Crank engine and observe indicator.
4. Push reset button and repeat step 3 twice.
LIGHTING GENERATOR COIL
OUTPUT
NOTE : The lighting generator coil is not part
of the ignition system. It is a separate sys-
tem that supplies current to the lighting system
and AC-powered devices. However it can be test-
ed with the same tester.
1. Disconnect wiring harness junction block at en-
gine (the one with YELLOW wires).
2. Connect tester wires then set switch and dial
as follows :
1. Yellow
3. Crank engine and observe indicator.
4. Push reset button and repeat step 3 twice.
Results :
a. Indicator lamp lights : Lighting generator
coil output is up to specifications.
b. Indicator lamp does not light : Lighting
generator coil is faulty.
Tester
wires
Component
wires
Tester
switch
position
Tester
dial
position
N
RED
wire of
magneto harness
LOW 85
P
BLACK / RED
wire of
magneto harness
Tester
wires
Component
wires
Tester
switch
position
Tester
dial
position
N
WHITE
wire of
magneto harness
LOW 75
P
BLACK / RED
wire of
magneto harness
N
WHITE
wire of
magneto harness
LOW 85
P
RED
wire of
magneto harness
N
A15E0UA
Red
Black / Red
Tester
wires
Component
wires
Tester
switch
position
Tester
dial
position
N
YELLOW
wire of
magneto harness
LOW 75
P
YELLOW
wire of
magneto harness
'
N
Yellow
A15E0VA
Yellow
