Ski-Doo Mach Z User Manual

Section 06 ELECTRICAL
Sub-Section 06 (TESTING PROCEDURE)
06-06-7
SUMMARY TABLE
Test to perform
Tester
wires
Components wires Switch Dial
Trigger coil output
N
BLUE / YELLOW
wire of
trigger coil
LOW
(All except
599 and 779)
35
P
WHITE / YELLOW
wire of
trigger coil
(599 and 779)
85
Ignition coil output
N Engine ground
LOW
(All except
599 and 779)
45
P
Test adapter
on MAG
spark plug cable
(599 and 779)
60
Ignition module output
N
WHITE / BLUE
wire (+)
of ignition coil
LOW 85
P
BLACK
wire (−)
of ignition coil
Magneto output
(ignition generator coil)
(All engines except
599 and 779)
N
RED
wire of
magneto harness
LOW 85
P
BLACK / RED
wire of
magneto harness
Magneto output
(ignition generator coil)
(599 and 779 engines only)
N
WHITE
wire of
magneto harness
LOW 75
P
BLACK / RED
wire of
magneto harness
Magneto output
(ignition generator coil)
(599 and 799 engines only)
N
WHITE
wire of
magneto harness
LOW 85
P
RED
wire of
magneto harness
Lighting generator coil
output
N
YELLOW
wire of
magneto harness
LOW 75
P
YELLOW
wire of
magneto harness
