Section 01 SERVICE TOOLS AND SERVICE PRODUCTS
sub-section 01 (SERVICE TOOLS)
SUSPENSION (Optional Service Tools)
A) Track cleat remover
m
A
(p/ N 5290082 00)
Pins
m
Ao
(p/ N 5290082 04)
o
NOTE : Pins can be rotated
180° depending on whether
the tool is used by a Ieft-hander
or right-hander.
A01B1J4
B) TRA track cleat
m
A
remover
(p/ N 5290287
00)
A01F224
APPLICATION
A) 1993 and older.
B) 1994 and newer except Elan
and Tundra Il.
Camber angle tool
m
A
(p/ N 5290216 00)
o
NOTE : Angle finder with
a magnetic base must be
used.
Suggestion : K-D tool no. 2968
IQ
~
A06B024
APPLICATION
All DSA front suspensions.
I
Track tension gauge
m
A
(p/ N 5290215 00)
AOOB3X4
APPLICATION
All models except Elan.
Track cleat installer
A) (p / N 5290085 00)
m
A
Narrow
B) (p / N 5290288 00)
m
Narrow
C) (p/N 5290077 00)
m
AA
Wide
A01B1M4
APPLICATION
A) 1993 and older.
B) 1994 and newer.
C) 1992 and older with wide cleat
opening.
Dome guide
(p/ N 529026500
m
~’
A06F1B4
APPLICATION
MX Z T / A shocks.
01-01-18
