Section 01 SERVICE TOOLS AND SERVICE PRODUCTS
Sub-Section 01 (SERVICE TOOLS)
Piston guide
(p/ N 5290266 00)
A06F1C4
m
00
APPLICATION
MX Z T / A shocks.
Suspension spring
installer (hook)
(p/ N 5290066 00)
A19B034
APPLICATION
Cheyenne.
SUSPENSION
Spring installer (bar)
m
●
(P/ N 5290050 00)
o
AOOC114
APPLICATION
Tundra
II LT, Scout and
all SC-1 O suspensions.
Spring cam adjuster key ~
(p/ N 8617317 00)
k
1
(
%
T
\/
3
2
A25BOD4
APPLICATION
Safari A-arm suspension spring.
Replacement parts :
1) Adjustment key
(p/ N 5290138
00)
2) Handle
(p/ N 5290140
()())
3) Key extension
(P/ N 5290139 00)
(OPtiOnal Service TOOIS)
Bushing installer /
m
remover
(p/ N 5290119
00)
9
5
I
4
A25B064
APPLICATION
A-arm suspension.
Parts included in the kit :
1) Buffer
(P/ N 5290118 00)
2) Outer sleeve
(p/ N 5290125
00)
3) Inner sleeve
(p/ N 5290126
00)
4) Hexagonal screw (2)
(p/ N 2220830 65)
5) Flat washer (2)
(p/ N 224 081201)
6) Lower retainer
(P/ N 5290121 00)
01-01-19

Ski-Doo Mach Z Specifications

General

Engine Displacement	899 cc
Horsepower	180 hp
Track Length	137 inches
Track Width	15 inches
Cylinders	2
Engine Stroke	2-Stroke
Cooling	Liquid
Fuel System	Electronic Fuel Injection (EFI)
Seating Capacity	1
Fuel Capacity	10.6 gallons
Brake System	Hydraulic
