Section 02 LUBRIFICATION AND MAINTENANCE
Sub-Section 01 (LUBRICATION AND MAINTENANCE CHART)
02-01-1
LUBRICATION AND MAINTENANCE
CHART 1
➀➁➂➃➄➅
REFER TO
Starting Rope Condition ✔ —
Engine Head Nuts ✔✔Appropriate section : See Top End
Engine Mount Nuts
✔✔
Appropriate section : See ENGINE
SUPPORT AND MUFFLER
Exhaust System
✔✔
Appropriate section : See ENGINE
SUPPORT AND MUFFLER
Engine Lubrication ✔ This section no. 1
Cooling System Condition ✔✔Sub-section 04-06
Coolant Replacement (Except Fan Cooled) ✔ Page 04-09-5
Condition of Seals ✔ Sub-section 04-03
Injection Oil Filter Condition (Except Élan) ✔ Page 04-07-1
Injection Oil Filter Replacement (Except Élan) ✔ Sub-section 04-05
Oil Injection Pump Adjustment (Except Élan) ✔✔Page 04-05-5
Fuel Stabilizer ✔ This section no. 2
Fuel Filter Replacement ✔ This section no. 3
Fuel Lines and Connections ✔✔Sub-section 04-09
Carburetor Adjustment ✔✔Page 04-08-8
Throttle Cable Inspection ✔✔✔Sub-section 04-09
Air Filter Cleaning ✔ This section no. 4
Drive Belt Condition ✔✔ This section no. 5
Condition of Drive and Driven Pulleys ✔✔✔Sub-sections 05-02 and 03-03
Cleaning of Drive and Driven Pulleys ✔ Sub-sections 05-02 and 03-03
Retorquing of Drive Pulley Screw ✔ Sub-section 05-02
Driven Pulley Preload ✔✔Sub-section 05-03
Brake Condition ✔✔ Sub-section 05-05
Brake Adjustment ✔ Sub-section 05-05
Lubrication of Ratchet Wheel or Fluid Change
(Except Élan)
✔ Sub-section 05-05
Drive Chain Tension ✔✔ Sub-sections 05-06 and 05-07
Countershaft Lubrication (S and F Series) ✔✔✔Sub-section 05-05
Chaincase / Gearbox Oil Level
(Change Once a Year)
✔ ✔✔✔ Sub-sections 05-06 and 05-07
Gearbox Oil Change (Skandic WT Only) ✔✔Sub-section 05-07
Lubrification of Drive Axle Bearing ✔✔✔Sub-section 07-05
To Next Page
