Ski-Doo Mach Z User Manual

Section 03 TROUBLESHOOTING
Sub-Section 01 (ENGINE)
03-01-7
6. Check antifreeze concentration.
a.Antifreeze concentration is too high.
Adjust concentration according to Bombardier’s recommendations.
7. Check tank cap.
a.Cap does not hold pressure.
Replace.
8. Check carburetion.
a.Improperly adjusted or inadequate carburetor components.
Adjust according to specifications (refer to TECHNICAL DATA 10) or replace inad-
equate component(s).
9. Check cylinder head gaskets.
a.Worn gaskets.
Replace.
10. Check ignition timing.
a.Ignition timing is too advanced.
Adjust according to specifications (refer to TECHNICAL DATA 10).
11. Check if there are leaks at air intake silencer and / or engine crankcase.
a.Leak(s).
Repair or replace.
12. Check condition and heat range of spark plug(s).
a.Melted spark plug tip or inadequate heat range.
Replace.
SYMPTOM ENGINE EQUIPPED WITH “RAVE” VALVE DOES NOT REACH ITS FULL OPERAT-
ING RPM (500 TO 1000 RPM SLOWER).
CONDITION NORMAL USE.
Test / Inspection 1. Check “RAVE” valve pistons.
a. Valve piston(s) is (are) too far out.
Screw valve piston(s) to bottom.
2. Check “RAVE” valve stems.
a. Bent “RAVE” valve stem(s).
Replace.
3. Check “RAVE” valves.
a. Jamed valve(s).
Clean.
4. Check tension of “RAVE” springs.
a. Inadequate spring tension.
Replace.
5. Check “RAVE” pressure holes.
a. Clogged holes.
Clean.
6. Check clamps or sleeves.
a. Damaged clamp(s) or sleeve(s).
Replace.

Ski-Doo Mach Z Specifications

General

Engine Displacement	899 cc
Horsepower	180 hp
Track Length	137 inches
Track Width	15 inches
Cylinders	2
Engine Stroke	2-Stroke
Cooling	Liquid
Fuel System	Electronic Fuel Injection (EFI)
Seating Capacity	1
Fuel Capacity	10.6 gallons
Brake System	Hydraulic
