Ski-Doo Mach Z User Manual

Section 03 TROUBLESHOOTING
Sub-Section 03 (TRANSMISSION AND BRAKE SYSTEM)
03-03-4
SYMPTOM BELT GLAZED EXCESSIVELY OR HAVING BAKED APPEARANCE.
CONDITION NORMAL USE.
Test / Inspection 1. Check if drive pulley bushings are worn.
a. Insufficient pressure on belt sides.
Replace bushing.
2. Check condition of drive pulley fixed half shaft.
a. Rusted drive or driven pulley shafts.
Clean shaft with fine steel woof and lubricate with low temperature grease (If
applicable only).
3. Check if pulley halves are clean.
a. Oil on pulley surfaces.
Clean pulley halves.
A00D0AY
4. Check pulley calibration.
a. Improper pulley calibration.
Calibrate according to specification.
SYMPTOM BELT WORN EXCESSIVELY IN TOP WIDTH.
CONDITION NORMAL USE.
Test / Inspection
A00D0BY
1. Check drive pulley.
a. Excessive slippage due to irregular outward actuation movement of drive pulley.
Carry out drive pulley inspection.
2. Check drive belt identification number.
a. Improper belt angle. (wrong type of belt).
Replace belt with an appropriate drive belt.
3. Check drive belt width.
a. Considerable use.
Replace belt if 3 mm (1/8”) less than recommended width (see TECHNICAL DATA 10).
Considerable
use
New belt

Ski-Doo Mach Z Specifications

General

Engine Displacement	899 cc
Horsepower	180 hp
Track Length	137 inches
Track Width	15 inches
Cylinders	2
Engine Stroke	2-Stroke
Cooling	Liquid
Fuel System	Electronic Fuel Injection (EFI)
Seating Capacity	1
Fuel Capacity	10.6 gallons
Brake System	Hydraulic
