Section 03 TROUBLESHOOTING
Sub-Section 03 (TRANSMISSION AND BRAKE SYSTEM)
03-03-7
BRAKE SYSTEM
MECHANICAL BRAKE
HYDRAULIC BRAKE
SYMPTOM BRAKE DOES NOT ADJUST AUTOMATICALLY.
CONDITION NORMAL USE.
Test / Inspection 1. Check ratchet wheel spring.
a. Broken ratchet wheel tag.
Replace.
2. Check mobile pad stud.
a. Stud rotates in pad.
Replace.
SYMPTOM BRAKE HANDLE DOES NOT RETURN COMPLETELY.
CONDITION NORMAL USE.
Test / Inspection 1. Check brake return spring.
a. Broken return spring.
Replace.
2. Check if brake cable moves freely in its housing.
a. Brake cable movement is limited due to oxidation or dirt accumulation.
Replace.
3. Check distance between brake lever and caliper.
a. Distance is too wide.
Adjust according to specifications (refer to TRANSMISSION section 05).
SYMPTOM SPONGY BRAKE CONDITION.
CONDITION NORMAL USE.
Test / Inspection
Replace brake fluid and bleed system. If problem still occurs, replace master cylinder.
SYMPTOM BRAKE FLUID LEAKING.
CONDITION NORMAL USE.
Test / Inspection 1. Check for loosen hose connectors.
Retighten.
2. Check for damaged hose, master cylinder and caliper.
Replace part(s) and check for proper mounting.

Ski-Doo Mach Z Specifications

General

Engine Displacement	899 cc
Horsepower	180 hp
Track Length	137 inches
Track Width	15 inches
Cylinders	2
Engine Stroke	2-Stroke
Cooling	Liquid
Fuel System	Electronic Fuel Injection (EFI)
Seating Capacity	1
Fuel Capacity	10.6 gallons
Brake System	Hydraulic
