Drive System (cont'd)
GTX/SUMMIT 9
Drive sprocket number of
te eth
MX Z/GSX
10
Bra ke system
H ydra ulic, R T™ type
brake lever
SUMMIT 406 mm (16 in)
Track nom inal widt h
Ot hers
381 mm (15 in)
GTX/SUMMIT 3456 mm (136 in)
Track nom inal length
MX Z/GSX
3072 mm (121 in)
X PAC KAGE 31.8 mm (1.25 in)
SUMMIT 44.5 mm (1.75 in)Track profile he ight
MX Z/GSX/GTX 22.2 mm (0.88 in)
Defl ect ion
30-35 m m
(1-3/16 - 1-3/8 in)
Track adjustment
Force
(1)
7.3kg(16lb)
Track alignment
Equal distance between
edges of track guides
and slider shoes
Suspension
Front suspension Double A -Arm
X PACK AGE HPG™ clicker T /A
Front shock
Others Moti on c ontro l
Front suspension max. travel 229 mm (9 in)
GTX/SUMMIT SC-136
Rear suspension
MX Z/GSX
SC-4™
X PACKAGE
HPG T/A
Front arm shock
Ot hers
Moti on c ontro l
166
