MODEL 4620 4626 4632
Weight
*
1980 kg 2170 kg 2300 kg
Overall width
Overall length
Platform Size (inside)
Working Height 8.1 m 9.9 m 11.8 m
Platform Elevated Height 6.1 m 7.9 m 9.8 m
Stowed Platform Height 1.0 m 1.1 m 1.2 m
Stowed Height (Railings Up) 1.96 m 2.15 m 2.24 m
Stowed Height (Railings Down) 1.6m 1.8m 1.9 m
Drive Height 6.1 m 7.9 m 9.7 m
Lift Time (No Load) 24 s 48 s 50 s
Lower Time (No Load) 48 s 45 s 62 s
Lift Time (Rated Load) 32 s 54 s 59 s
Lower Time (Rated Load) 32 s 32 s 49 s
Normal Drive Speed
Elevated Drive Speed
High Torque Drive Speed
Gradeability (Ramp Angle) 25%
Tires (Solid Rubber)
Type
Tank Capacity (Liters)
131AA
Note :
Emission sound pressure level does not exceed 70 dB(A).
1.1 m x 2.1 m
2.3 m
1.2 m
Standard Operating Times
Chassis
3.2 km/h
Height
30%
16 x 5 x 12
1.6 km/h
1 km/h
Hydraulic Oil
ATF Dexron III
30
* Weight with standard 1.2m extension platform. Refer to serial nameplate for specific
applications.
