131
SJ30AJE, SJ30ARJE 196274AF
Platform Section 5 – Procedures
5.2-2 SCM Character Functions Charts
SCM Keypad
Keys Short Form
Menu/Select (M/S)
/-
(-)
/+
(+)
Save/Exit (S/E)
1345AA
Function Attribute
THRESH Threshold
RAMPDN Ramp Down
RAMPUP Ramp Up
LOWRNG Low Range
MAXOUT Maximum Output
SCM Function (Channel) Names
FLOW ENABLE Fn01A Flow Enable
RISER DN 2A Fn05A Riser Down
RISER UP 2B Fn05B Riser Up
BOOM DOWN Fn03A Main Boom Down
BOOM UP Fn03B Main Boom Up
ROTATE L Fn04A Turret Rotate Left
ROTATE R Fn04B Turret Rotate Right
