132
SJ30AJE, SJ30ARJE196274AF
Section 5 – Procedures Platform
5.2-3 SCM Operating Values Chart
Input (Analog) Expected Value Description
AI 1 0.5V to 8.5V Riser Switch (Resistors)
AI 2 0.5V to 8.5V Turret Rotate Controller
AI 3 0.5V to 8.5V Boom Elevation Controller
AI 4 0.5V to 8.5V Rotary Speed Selector
AI 6 0.5V to 8.5V Fly Boom Switch (Resistors)
AI 7 0.5V to 8.5V Jib Elevation Switch (Resistors)
Input (Digital) Expected Value Description
DI 1 0 or 1 Jib Rotate Common
DI 3 0 or 1 Platform Rotate Common
DI 4 0 or 1 Platform Level Common
DI 5 0 or 1 Master Enable
DI 11 0 or 1 Stowed Limit
Output (Digital) Expected Value Description
DOUT 1 0 or 1 Riser Down Active
DOUT 2 0 or 1 Jib Up Valve
DOUT 3 0 or 1 Platform Level Allowed
DOUT 4 0 or 1 Jib Down Valve
DOUT 7 0 or 1 Fly Out Valve
DOUT 8 0 or 1 Fly In Valve
1387AA
For Output (PWM) values, refer to 5.2-6 How to Set the SCM Valve Characteristics.
