SKYLOTEC SIRIUS - Nomenclature of Parts; Device Marking

4
2. MARKING
1. NOMENCLATURE OF PARTS
1a
1a
1b
1b
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
HANDLE
ROPE INLET (free rope)
ROPE OUTLET (working rope)
HANDLE’S SAFETY LATCH
ATTACHMENT HOLE
BECKET
CAM
OPENING BUTTON
FIXED JAMMING ELEMENT
TOP SIDE PLATE
BOTTOM SIDE PLATE
HOUSING
1
2
3
4
5
6
7
8
9
P
S
R
E
S
ANSI/ASSE Z359.4
1-person load
59-141kg / 130 - 310 lb
Max. 28 descents
11mm, H 190m
EN 12841-C
10-12mm, 250kg
EN 341:2011/2A
H 190m,
Tmin -30°C
11mm, 30-200kg
Im Mühlengrund 6-8 D-
56566 Neuwied
Use only compatible rope.
Ser.-No. (xxxxxx)xxx
MM/YYYY
Avoid descending into el.,
therm., and chem. hazards.
k
51
S
N
BM
Month
MANUFACTURE DATE
T R A C E A B I L I T Y
Individual number
Year
Ser.-No. (xxxxxx)xxx
MM/YYYY
9
BODY CONTROLLING THE MANUFACTURING OF PPE
MAT-BA-0203-00_20191002.indd 4 29.10.2019 15:38:38
