Page 9
Item Part No. Description Qty.
1. RADIAL ARM ASSEMBLY
1 B2-010-01 STANDARD MOUNTING PLATE ................................................................................. 1
2 ----- JUNCTION BOX .......................................................................................................... 1
3 B2-210-07 •COVER,junctionbox ................................................................................................. 1
4 B9-210-23 •SCREW,junctionboxcover ....................................................................................... 4
5 ----- SUPPORT HUB ....................................................................................................... A/R
6 B2-010-02 MOUNTING BOLT, 1/2-13 ............................................................................................ 6
7 B2-210-31 CEILING COVER ......................................................................................................... 1
8 B2-210-11 TAPERED ROLLER BEARING ................................................................................ A/R
B2-210-12 BEARING CUP ........................................................................................................ A/R
9 B2-710-10 SLIP RING, 8 position .............................................................................................. A/R
B9-210-13 SLIP-RING, 3 position .............................................................................................. A/R
10 B2-210-14 SET SCREW, slip ring ............................................................................................. A/R
11 B2-210-18 SCREW,covermounting ......................................................................................... A/R
12 B2-310-05 BRUSH BLOCK AND COVER ASSEMBLY, (3 pos.) ............................................... A/R
B2-710-11 BRUSH BLOCK AND COVER ASSEMBLY, (8 pos.) ................................................ A/R
13 B2-210-19 BRAKE SCREW ...................................................................................................... A/R
14 B2-210-26 NUT, retainer ................................................................................................................ 1
15 B2-210-27 SET SCREW ................................................................................................................ 1
16 B2-210-58-1 COVER, hub, with chain............................................................................................... 1
17 B2-210-29 SCREW,hubcoverretainer ......................................................................................... 3
18 B2-210-57 RETAINER,hubcover .................................................................................................. 1
19 B2-210-56 SPACER ....................................................................................................................... 3
20 B3-310-01 VERTICAL SUPPORT TUBE ................................................................................... A/R
B3-410-01-2 VERTICAL SUPPORT TUBE, AUR TV .................................................................... A/R
21 ----- CONNECTOR, crimp ............................................................................................... A/R
22 B3-210-12 VSTSCREW,M6x12 ............................................................................................. A/R
23 ----- RADIAL ARM ........................................................................................................... A/R
24 B2-410-12 COVER, rubber ........................................................................................................ A/R
25 B2-410-16 RING,ceilingcoverspacer .......................................................................................... 1
26 B2-710-13 CONNECTOR, D-sub., female. ................................................................................ A/R
27 B2-710-14 CONNECTOR, D-sub., male .................................................................................... A/R
NS B2-410-14 LABEL, “SKYTRON”, Radial Arm ................................................................................ 2
To Next Page
