Skywalker OWTC12 - Page 12

JTEC12B
1
3
2Top Tube with T-joint (6 pcs) Top Tube with Socket (6 pcs)
Leg extension (12 pcs)
5 Jumping mat (1 pc) 6 Frame PAD (1 pc)
4 Leg brace (6 pcs)
7 Enclosure net (1 pc)
10 Curved Tube (6 pcs)
13 End Cap (6 pcs)
16 Spring Tool (1 pc)
17 Screw Driver (1 pc)
14 M5x50mm Bolt (6 pcs)
15
M4.8x16mm Self-tapping
Screw(33 pcs), 3 spare parts
11 Foam (12 pcs)
12 Pole Cap (6 pcs)
8 Spring (72 pcs)
9 Straight Tube（6 pcs）
Use below drawings to identify all the parts.
R
