REFRIGERATOR
INSTRUCTION MANUAL
ITEM:SRD-199DB
Dear Customer
Please read these Operating Instructions carefully before you connect your new refrigerator as they contain important in-
formation on its safe and proper use, installation and care. Please keep the Operating Instructions in a safe place for future
reference. Moreover, please pass them on to possible new owners of the appliance.
General Description of Refrigerator
Transportation and Handing
When transportating, hold the base and lift the refrigerator carefully with the tilted angle more than 45 degree. Never hold
the door handle as support. Never place it upside down nor horizontalwise nor get it extruded. Push refrigerator about by
making its two hind roller feet as axis and then tilting it slightly during moving indoors.
Installation
1.Install the refrigerator at a place with a flat, firm ground directly. In order to prevent vibration and noise.
2.Choose a well-ventilated place. A space of no less than 10cm must be left around the refrigerator.
3.Choose a location where there is no heat source. Keep the refrigerator away from direct sunlight and oven etc..
4.Choose a dry and well-ventilated place where there is no corrosive air.
Testing
and wipe them dry.
Notes: Electric parts of the refrigerator can only be wiped by dry cloth.
2. Turn the thermostat knob to the "3" position, turn on electricity. The compressor and the light inside the refrigerator
begin to work.
3. Close the door 30 minutes later, if the temperature in the freezer compartment decreased obviously, it shows that the
refrigerator system works well. When the refrigerator operates for a period of time, the temperature controller will auto-
matically set the temperature within limits it opens.
4. If the above steps are successful, the trial operations finish. The refrigerator works normally.
Temperature Control
1. The temperature in the refrigerator compartment and freezer compartment is controlled by the temperature
controller installed on the top wall of the refrigerator compartment.
2. Turn the thermostat knob to right or left, you can regulate the temperature inside the refrigerator.
3. The marks on the knob are the temperature grades, not the exact number of the degrees of temperature.”0”
shows a forced STOP and "7" shows the lowest temperature. Turn the knob from "1"position to "7"position, the
temperature decreases continuously. You may set the temperature control selector to any position according to what you
need.
4. Please set the selector to"4"position in normal use.
Storage of Food
1.How to Use the Freezer Compartment
*Put fresh and clean food such like fish, meat into freezer to frozen store, therefore the taste and nutrient of food are
preserved.
*Wrap food to be frozen in ALUMINIUM FOIL or place it in AIRTIGHT boxes.
*Do not allow already frozen food into direct contact with food to be frozen.
*If you buy deep frozen food in the shops, bring it home and place it in freezer as quickly as possible so that the time during
which it kept in the air temperature is as SHORT AS POSSIBLE.
2. How to Use the Refrigerator Compartment
*The cook dishes can be put into refrigerator to keep fresh after their temperature decreases to room temperature.
*Egg tray and upper rack for eggs.middler rack and lower rack for milk and bottle drinks, etc.
*Other food such as MEAT, FISH AND suchlike, in addition to becoming dry, may cause smells. To prevent this, they
should be wrapped in aluminum foil, placed in suitable polythene bags or stored in proper airtight containers.
3. Placement of Food
*Proper place should be left instead of too crowded during food storage.
*Food to be stored should be wrapped with clean plastic film or fresh keeping paper, then distributed to several frames
even to avoid contamination and the loss of water and smell mixture.
*Cool hot food down to the room temperature before storing or consumption of electricity will increase and would lead to
frost forming inside.
*Never place vegetables and fruits into freezer compartment in order to prevent them from being frostbitten.
Defrosting
1. When the refrigerator working for a period of time, the inner surface of the freezer will be covered with a layer of white
frost. It may raise the electricity consumption and lessen the effect of refrigeration. Then you should do frost removement
at once.
2.When defrosting,cut off the power,open the door and move frozen foods to a shady and cooling place,defrost with a plastic
scraper, or let the temperature rise naturally till frost melts.Then wipe away remaining ice and water,and switch on
electricity again.
Notes: Never use sharp metal tools or it will damage the refrigerator.
1
2
3
1 Thermostat Control
(Interior Light)
2 Refrigerator Shelf
SRD-199DB
1
3
1
4
2
4
3 Salad Crisper Cover
4 Salad Crisper
5 Adjustable Foot
6 Door Storage
(Picture shown for indicative purposes only, model supplied may differ).
