The selection of screen power supply with jumper cap in above photo, from top to bottom :3.3V/5V/12V.
NO. Definition Property Description
1
PVCC
Power
output
LCD power output，+3.3v/+5V/ +12V Optional
2
3
4
GND
ground
electrode
ground electrode 5
6
7 0-VN0 Output Pixel0 Negative Data (Odd)
8 0-VP0 Output Pixel0 Positive Data (Odd)
9 0-VN1 Output Pixel1 Negative Data (Odd)
10 0-VP1 Output Pixel1 Positive Data (Odd)
11 0-VN2 Output Pixel2 Negative Data (Odd)
12 0-VP2 Output Pixel2 Positive Data (Odd)
13 GND
ground
electrode
ground electrode
14 GND
ground
electrode
ground electrode
15 0-VNC Output Negative Sampling Clock (Odd)
16 0-VPC Output Positive Sampling Clock (Odd)
17 0-VN3 Output Pixel3 Negative Data (Odd)
18 0-VP3 Output Pixel3 Positive Data (Odd)
19 1-VN0 Output Pixel0 Negative Data (Even)
20 1-VP0 Output Pixel0 Positive Data (Even)
21 1-VN1 Output Pixel1 Negative Data (Even)
22 1-VP1 Output Pixel1 Positive Data (Even)
23 1-VN2 Output Pixel2 Negative Data (Even)
24 1-VP2 Output Pixel2 Positive Data (Even)
25 GND
ground
electrode
ground electrode
26 GND
ground
electrode
ground electrode
27 1-VNC Output Negative Sampling Clock (Even)
28 1-VPC Output Positive Sampling Clock (Even)
29 1-VN3 Output Pixel3 Negative Data (Even)
30 1-VP3 Output Pixel3 Positive Data (Even)
31 0-VN4 Output Pixel4 Negative Data (Odd)
32 0-VP4 Output Pixel4 Positive Data (Odd)
33 1-VN4 Output Pixel4 Negative Data (Even)
34 1-VP4 Output Pixel4 Positive Data (Even)
