Smart system Smart 2 lite - DIP Switch Configuration; Transducer Working Mode and Time Settings; Burst and Power Settings; Transducer Type and Example Settings

Switch 1 Transducer working mode
Switch 2 Transducer working time in cyclic mode
Switch 3 Burst frequency 20-55 kHz
Switch 4 Burst time
Switch 5 Pause time between bursts
Switches 6 and 7 Power settings
Switch 8 Transducer type
Examples
Both together Cyclic
5 seconds 10 seconds
Random
Swap
Long (higher consumption, higher efficiency)Short (lower consumption, lower efficiency)
Long (lower consumption, lower efficiency) Short (higher consumption, higher efficiency)
Low power Medium power 1 Medium power 2 High power
Single band 40 kHz Dual band 25 / 45 kHz
DIP switch settings
By default Highest consuption
Lowest consuption
