Pushing away the instrument panel
Page 18 Guidelines for Rescue Services, smart, 2006
Rescue
• Crush the rocker panel near the Apillars
using the spreader
P63.00204900
• Cut through the rocker panel using rescue
shears
P63.00205000
• Make a depression at the bottom towards the
rear of the rocker panel near the Bpillar and
install the telescopic rescue ram
• Position the other end of the rescue ram on the
Apillar level with the instrument panel. To
prevent the base of the rescue ram from
breaking through, make sure that the
supporting points are strong.
• Extend the rescue ram as far as necessary
• To prevent vehicle parts from springing back,
the rescue ram should be left under pressure
until the casualty or casualties have been
rescued from the vehicle
P63.00205100
