TESTING & REPAIR
TESTING AND REPAIR WORK: SMART: ELECTRICAL SYSTEM, EQUIPMENT AND
INSTRUMENTS - AR54.00-Z-9451CA
MODEL 451
skin and eyes from battery acid or
when handling damaged lead-acid
batteries
suitable and appropriately
marked containers.
Notes on battery AH54.10-P-0001-01A
1 Remove footrest on the passenger-
side
Left-hand drive vehicles AR68.30-P-1340MCC
Right-hand drive vehicles AR68.30-P-1340MCE
2 Unscrew nut (3)
3 Unclip the retaining clip (2) on the
bracket (1) and remove bracket (1)
On right-hand drive
vehicles the bracket (1) is
only raised until the stop
plugs (4) are accessible.
Checking
4 Remove stop plugs (4) on the
battery (G1) and check fluid level
in the battery (G1)
In each cell the fluid
must reach the web let into
the filler opening (arrow).
Correct
5 Correct the battery acid level with
distilled water
Refill distilled water up
to the web (arrow).
6 Screw in plug (4)
Install
7 Insert bracket (1) and clip in
retaining clip (2) at the bracket (1)
8 Tighten nut (3)
Installation: Replace
self-locking nut (3).
9 Install footrest on the passenger-
side
Left-hand drive vehicles AR68.30-P-1340MCC
Right-hand drive vehicles AR68.30-P-1340MCE
Perform initial startup of control units MODEL 451.3/4 AR54.21-P-0018MCE
Charge battery MODEL 451.3/4 AR54.10-P-1130MCC
Check condition of battery MODEL 451.3/4 AR54.10-P-1129MCC
Check quiescent current consumption MODEL 451.3/4 AR54.10-P-1030MCE
Control unit flashing MODEL 451.3/4 AR54.21-P-0012MCC
Control unit flashing MODEL 451.3/4 AR54.21-P-0012MCU
Disable/enable high-voltage system MODEL 451.391/491 with ENGINE
780.009
AR54.10-P-1160MEV
Disconnect/connect battery ground
line
MODEL 451.3/4 AR54.10-P-0003MCC
Disconnecting and connecting
electrical cables from battery
MODEL 451.3/4 AR54.18-P-0002MCC
