Press and hold the P1 button on the motor head for 6 seconds. The green LED
light will flash twice, followed by the red LED light flash three times, indicating
the motor is in pairing mode and ready for app connection.
1. Remove the back cover of the remote.
2. Briefly press the P button until the motor jogs once.
3. Press the UP button until the motor jogs again.
4. Press the P button once more until the motor jogs once.
5. A red LED light will flash three times, indicating the motor is in pairing mode
and ready for app connection.
UP
SETTING
(P)
SETTING
(P)
0000
0000
Add HomeKit Device
· Pairing Method 1:
· Pairing Method 2:
5
Scan the QR code stick on the shade to add it.
Note: Ensure that the operations are performed on the correct channel corresponding to
the motor you wish to pair.
Compatible with the drapery
Enter the pairing mode
pairing mode
