EX500-TF2Z176EN
Page 2 of 2
5 Setting (continued)
Refer to the operation manual on the SMC website (URL:
https://www.smcworld.com
) for further information on switch settings.
5.4 Configuration
Technical documentation giving detailed configuration information can
be found in the operation manual on the SMC website (URL:
https://www.smcworld.com).
6 LED Display
• Branch port status
LED Description
COM A
COM B
COM C
COM D
7 Outline Dimensions (mm)
Refer to the operation manual on the SMC website (URL:
https://www.smcworld.com
) for outline dimensions.
8 How to Order
Refer to the operation manual on the SMC website (URL:
https://www.smcworld.com
) for How to order information.
9 Maintenance
9.1 General Maintenance
Caution
• Not following proper maintenance procedures could cause the
product to malfunction and lead to equipment damage.
• If handled improperly, compressed air can be dangerous.
• Maintenance of pneumatic systems should be performed only by
qualified personnel.
• Before performing maintenance, turn off the power supply and be
sure to cut off the supply pressure. Confirm that the air is released to
atmosphere.
• After installation and maintenance, apply operating pressure and
power to the equipment and perform appropriate functional and
leakage tests to make sure the equipment is installed correctly.
• If any electrical connections are disturbed during maintenance,
ensure they are reconnected correctly and safety checks are carried
out as required to ensure continued compliance with applicable
national regulations.
• Do not make any modification to the product.
• Do not disassemble the product, unless required by installation or
maintenance instructions
• Stop operation if the product does not function correctly.
10 Limitations of Use
10.1 Limited warranty and Disclaimer/Compliance Requirements
Refer to Handling Precautions for SMC Products.
11 Product Disposal
This product shall not be disposed of as municipal waste. Check your
local regulations and guidelines to dispose of this product correctly, in
order to reduce the impact on human health and the environment.
12 Contacts
Refer to www.smcworld.com or www.smc.eu for your local distributor /
importer.
URL: https://www.smcworld.com (Global) https://www.smc.eu (Europe)
SMC Corporation, 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021, Japan
Specifications are subject to change without prior notice from the manufacturer.
© 2021 SMC Corporation All Rights Reserved.
Template DKP50047-F-085M
LED Description
MS
Power supply for input and control OFF
NS
EtherNet/IP
TM
communication established
Green flashing
EtherNet/IP
TM
communication not
established
EtherNet/IP
TM
communication time out
IP address has been duplicated
PWR(V)
Power supply for solenoid valves is OFF
Power supply for solenoid valves is ON
PI
OFF
Forced output mode is disabled
(Operating normally)
Ethernet UCMP Echo request (Ping
command) received.
L/A1
No Link, No Activity (Port1)
Link, No Activity (Port1, 100 Mbps)
Link, Activity (Port1, 100 Mbps)
Link, No Activity (Port1, 10 Mbps)
Link, Activity (Port1, 10 Mbps)
L/A2
No Link, No Activity (Port2)
Link, No Activity (Port2, 100 Mbps)
Link, Activity (Port2, 100 Mbps)
Link, No Activity (Port2, 10 Mbps)
Link, Activity (Port2, 10 Mbps)
