Smeg KSEI62E2 - Connections; Ducted Version Air Exhaust System; Air Outlet in Recycling Version; Electrical Connection

EN
1
19
&RQQHFWLRQV
'8&7('9(56,21$,5(;+$8676<67(0
When installing the ducted version, connect the hood to the
chimney using either a flexible or rigid pipe ø120 mm, the choice
of which is left to the installer.
• Fix the pipe in position using sufficient pipe clamps (not sup-
plied).
• Remove any activated charcoal filters.
ø 120
9
$,5287/(7,15(&<&/,1*9(56,21
• Make sure that the hood body has been completely fixed.
• Make sure that hood is equipped with charcoal filters.
(/(&75,&$/&211(&7,21
• Connect the hood to the mains through a two-pole switch hav-
ing a contact gap of at least 3 mm.
• Remove the grease filters (see paragraph Maintenance) being
sure that the connector of the feeding cable is correctly inserted
in the socket placed on the side of the fan.
