102
Installation
Burner and nozzle characteristics table
1 Natural Gas G20 AUX SR R DUAL int. DUAL ext.
Rated heating capacity (kW)
1.0 1.8 2.9 0.9 4.10
Nozzle diameter (1/100 mm)
72 97 115 70 150
Pre-chamber (printed on nozzle)
(X) (Z) (Y) (H1) (H3)
Reduced flow rate (W)
400 500 800 400 1200
2 Natural Gas G20 AUX SR R DUAL int. DUAL ext.
Rated heating capacity (kW)
1.1 1.8 2.9 0.9 4.10
Nozzle diameter (1/100 mm)
72 94 110 65 145
Pre-chamber (printed on nozzle)
(X) (Z) (H8) (H1) (H3)
Reduced flow rate (W)
400 500 800 400 1200
3 Natural Gas G25 AUX SR R DUAL int. DUAL ext.
Rated heating capacity (kW)
1.0 1.8 2.9 0.9 4.10
Nozzle diameter (1/100 mm)
72 94 121 68 142
Pre-chamber (printed on nozzle)
(F1) (Y) (F2) (F1) (F3)
Reduced flow rate (W)
400 500 800 400 1200
4 Natural Gas G25.1 AUX SR R DUAL int. DUAL ext.
Rated heating capacity (kW)
1.1 1.8 3.0 0.9 4.0
Nozzle diameter (1/100 mm)
77 100 134 72 148
Pre-chamber (printed on nozzle)
(F1) (Z) (F3) (H1) (F3)
Reduced flow rate (W)
400 500 800 400 1200
5 Natural Gas G25 AUX SR R DUAL int. DUAL ext.
Rated heating capacity (kW)
1.0 1.8 2.9 0.9 3.8
Nozzle diameter (1/100 mm)
77 100 134 72 165
Pre-chamber (printed on nozzle)
(F1) (Y) (F3) (F1) (H3)
Reduced flow rate (W)
400 500 800 400 1200
6 Natural Gas G2.350 AUX SR R DUAL int. DUAL est.
Rated heating capacity (kW)
1.0 1.75 2.9 0.9 3.2
Nozzle diameter (1/100 mm)
94 120 165 91 180
Pre-chamber (printed on nozzle)
(Z) (Y) (F3) (Y) (H4)
Reduced flow rate (W)
400 500 800 400 1200
