16
Pump Setup
Medical. The rechargeable battery pack can easily
be recharged with the AC adapter, either inside or
outside of the pump. See the rechargeable battery
pack’s instructions for use for more information.
Cassette
The cassette is the part of the medication cassette
reservoir or CADD
®
administration set that attaches
to the bottom of the pump. The following single-use
products are compatible with the pump:
• Medication cassette reservoir, used with a
CADD
®
extension set.
• CADD
®
administration set.
WARNING: Follow the instructions for use
providedwiththeCADD™medicationcassette
reservoir,CADD
®
extension set, or CADD
®
administration set, paying particular attention
to all warnings and cautions associated with
their use. Incorrect preparation and/or use of
these products could result in serious patient
injury or death.
NOTE: A CADD
®
set with free-flow protection
must be used in order to prevent free-flow.
NOTE: Smiths Medical recommends that the
appropriate supplies needed to replace the cassettes
are available in case of a damaged cassette.
NOTE: For detailed instructions and warnings
pertaining to the medication cassette reservoir
or CADD
®
administration set, please refer to the
instructions for use supplied with the product for
preparing the product for use.
Remote Dose Cord
The remote dose cord can be attached to the pump
and provided to the patient as an alternative to
pushing the PCA dose @ key when requesting
a PCA dose. The LED on the remote dose cord
indicates PCA dose status:
• Off: A PCA dose is not available.
• Flashing: A PCA dose is available.
• On: A PCA dose has been requested and
delivery has started.
Refer to the instructions for use provided with the
remote dose cord for more information.
Polemount Bracket Adapter
The optional polemount bracket adapter attaches
onto the back of the pump. This allows you to attach
the pump to an IV pole. Refer to the instructions for
use provided with the polemount bracket adapter
for information.
Polemount Bracket
The polemount bracket is used along with the
polemount bracket adapter to attach the pump to an
IV pole. Refer to the instructions for use provided
with the polemount bracket for information.
Pump Key
The pump key is used to securely lock the cassette
to the pump. It can also be used to lock and unlock
the keypad, if allowed by the CADD®-Solis system
administrator.
