Smiths Medical CADD-Solis User Manual

46
References and Troubleshooting
 EN55011(1998), Industrial, scientific and
medical (ISM) radio frequency equipment
- Radio disturbance characteristics - Limits
and methods of measurement. Amendment 1
(1999), Amendment 2 (2002)
Miscellaneous Standards
 USB1.1Universal Serial Bus (USB)
Specification, Revision 1.1, September 23,
1998 – USB.org
EN1041(1998), Information supplied by the
manufacturer with medical devices.
 IEC/TR60878(2003), Graphical symbols for
electrical equipment in medical practice.
 EN980(2003), Graphical symbols for use in
the labeling of medical devices.
 IEC60529(2001), Degrees of protection
provided by enclosures (IP Code).
Specifications (Nominal)
General Pump Specications
Medication cassette reservoir, part number 21-7002,
CADD
®
extension sets, part number 21-7045, and
CADD
®
administration sets, part number 21-7091
were used to test the pump.
Resolution
Medication cassette reservoir or CADD
®
administration set, 0.050 mL per pump stroke
nominal.
Size
4.1 cm × 10.2 cm × 12.7 cm [1.6 in. × 4 in. ×
5in.] excluding cassette or other accessories.
Weight
595 g [21 oz.] including 4 AA alkaline batteries,
excluding other accessories.
Pump Alarms
The following alarms are all considered to be
high priority alarms: Battery depleted while
delivering; Battery removed while delivering;
Battery unusable while delivering; Rechargeable
battery end of life; Disposable detached while
delivering; Disposable attached improperly;
Disposable type high flow administration set;
Disposable type invalid; Disposable locked but
not latched; Reservoir volume empty; Pressure
sensor faulty; Downstream occlusion; Upstream
occlusion; Air in line detected; Remote dose
cord key stuck; Key stuck; Stop mode reminder;
Pump was automatically stopped.
There are an additional 19 medium
priority alarms, 8 low priority alarms, and
20informational messages alerts.
Battery Fallout Alarm
Alarm sounds for 2 minutes if the pump has
been powered up for a minimum of 2 minutes.
NOTE: Only enabled while pump is in run
mode.
Battery Status
Battery State CADD® Pump Status
25%—100% No alarm
Low battery Transition to low battery
condition; battery low message
appears; 3 beeps every 5min.
†
LCD backlight will ash for 12ms
during each motor operation.
Depleted
battery
Transition to depleted battery
condition; battery depleted
message appears; pump beeps
continuously.
††
Shut down Pump shuts o due to too low
operating voltage.
CADD®-Solis pump low battery conditions.
†
The pump emits 3 beeps every 5 minutes, and the low battery warning
message appears on the pump’s display, indicating that the battery
power is low, but the pump is operable.
††
The pump emits a continuous, variable-tone alarm, and the depleted
battery warning message appears on the display, the battery power is
too low to operate the pump, and the pump delivery operation has
stopped.
ContinuousDeliveryAlkalineBatteryLife
withscreenintensitysetto3
Rate Life Volume
0.4 mL/hr 260 hrs 104 mL
1 mL/hr 210 hrs 210 mL
5 mL/hr 165 hrs 825 mL
10 mL/hr 150 hrs 1500 mL
30 mL/hr 70 hrs 2100 mL
