Scout Trailer Kit
Part#87400/87400-01
Back Drawer BOM list
Component Name Qty
Secondary
Component
Name Qty
Work piece
Back drawer
(Negative)
1
Accessories
1000 mm slider
（
right side
with self
-lock
，
left side
without self
-
lock
）
2 Hardware
M5*16 stainless steel bolt
18
φ5 stainless steel flat
washer
8
φ5 stainless steel lock
washer
8
M5 stainless steel nut
8
Handle
1
Hardware
M4*6 stainless steel bolt
2
φ4 stainless steel flat
washer
2
φ4 stainless steel lock
washer
2
Latch
1
Hardware
M5*16 stainless steel bolt
4
φ5 stainless steel flat
washer
4
φ5 stainless steel lock
washer
4
M5 stainless steel nut
4
Loop
6
Hardware
M5*8 rivet
6
