Key:
1-Lower Grill
2-Outer Edge
3-Support Tabs
4-Kettle Tab
5-Water Pan
Installing the Smokenator™
Starting with a clean kettle lid, make sure the interior of the
kettle top is brushed clean of accumulated smoke flakes. Keep the
lower kettle free of accumulated smoke residue, ash, and soot.
This keeps each smoking session free of harshness.
Arrange the coal support grill (1the lower grill + support
rods) so that the base of the baffle fits in between the main rods (1)
of the coal support grill. The top outer edge of the Smokenator™
(2) is supported by two of the upper cooking grill’s support tabs
(3). Arrange the baffle so that the bent tabs of the baffle (4) are
positioned directly over the kettle tabs (3) that are used to support
the cooking grill. This allows the baffle to be lightly secured to the
kettle.
Items included:
* Smokenator™ 1000 Baffle
* Stainless Steel Pan
* 12” Skewer for Pushing Coals
