SMSL D300 - Page 15

Display Interface and Instructions
Bluetooth antenna
KnobRemote windowDisplay
USB input
D300
5 6
9
7
8
1
2 3
4
10
11
AC IN(100-240VAC)
Turn on / off button**
FN button*
RCA output
Menu button
Balanced output
Coaxial input Optical input
12
13
53
9
4
8
7
6
10 11
12
13
2
1
* FN button: This button can define its function in the menu "FN KEY FOR"
**Turn on / off button: PRESS to switch the INPUT, HOLD for POWER ON/OFF
