SMSL PL100 - Page 15

Display Interface and Instructions
Play_pause / power on_off
5 6
STOP/ Open_Close
Next/Fast reverse
Previous/Fast forward
Volume downVolume up
1
2 3
4
Indicator light
8 9
Display Remote window
7
Coaxial output
11 12
Optical outputDisc slot
10
RCA output
14 15
USB input(5V/2A)3.5mm headphone output
13
1
14
2
345610
89
7
15
13
1211
