ATI520J Portable Cable Terminal Swager Operating and Maintenance Manual
Page 5 of 12
SWAGING TIME AND DIMENSIONAL DATA FOR SWAGED TERMINALS
TERMINAL
TERMINAL
AN
PART #
MS
DASH #
CABLE
DIA.
MIN.
“B
s
DIA
MAX.
MIN.
“A
s
DIA.
MAX.
MIN.
DIE PART #
SWAGE
TIME IN
SEC.
MS21259
MS20667
MS20668
MS21260
-2
1/16
1.147
-
.138
.133
ATI520CS-2
15
-3
3/32
1.305
-
.190
.185
ATI520CS-3
15
-4
1/8
1.694
-
.219
.214
ATI520CS-4
20
-5
5/32
2.033
-
.250
.245
ATI520CS-5
35
-6
3/16
2.106
-
.313
.308
ATI520CS-6
45
-7
7/32
2.484
-
.375
.368
ATI520CS-7
30
-8
1/4
2.373
-
.438
.431
ATI520CS-8
100
AMERICAN
CHAIN &
CABLE
RA2487
-2
1/16
-
.1905
.1875
-
ATI520CB-2
5
-3
3/32
-
.253
.250
-
ATI520CB-3
6
-4
1/8
-
.315
.312
-
ATI520CB-4
8
MS20664
-2
1/16
.156
.190
.187
.112
.109
ATI520CSB-2
6
-3
3/32
.234
.253
.250
.143
.140
ATI520CSB-3
8
-4
1/8
.313
.315
.312
.190
.187
ATI520CSB-4
10
-5
5/32
.391
.379
.375
.222
.218
ATI520CSB-5
30
-6
3/16
.469
.442
.437
.255
.250
ATI520CSB-6
100
MS20663
-2
1/16
.390
.190
.187
.112
.109
ATI520CDB-2
6
-3
3/32
.578
.253
.250
.143
.140
ATI520CDB-3
8
-4
1/8
.765
.315
.312
.190
.187
ATI520CDB-4
10
-5
5/32
.953
.379
.375
.222
.218
ATI520CDB-5
30
-6
3/16
1.140
.442
.437
.255
.250
ATI520CDB-6
60
