Amplifier Panel
Main
Speakers
Receiver
+
LR
-
HIGH LEVEL IN FROM AMP
L
+– R+–
HIGH LEVEL OUT TO MAIN SPEAKERS
Amplifier Panel
Main
Speakers
Receiver
+
LR
-
HIGH LEVEL IN FROM AMP
L
+– R+–
HIGH LEVEL OUT TO MAIN SPEAKERS
Option 2
Connect both the subwoofer and the main speakers
to the back of the receiver.
Option 3
Connect the amplifier to the main speaker system
and the main speaker system to the subwoofer in.
