3
Specification PS.10 Powered Subwoofer
Frequency Response (
±
3dB) 32-125Hz
27Hz at -6dB
Amplifier Power 300 watts
Crossover Low Pass for Subwoofer Variable from 50 to 125Hz
Crossover High Pass for Line Out Fixed at 80Hz, 12dB/octave
Bass Unit 10-inch (250mm) custom-built bass unit with dual
spiders, top-mounted heat sink, and die-cast
aluminum chassis. With coated paper cone and butyl
surround. Video-shielded.
Cabinet Construction Hardwood veneer on
3
¼
4
-inch MDF.
Internal Double-H bracing.
Grille Guillotine-style black cloth covered grille
Controls
fi Phase Switch
fi Auto On-Off switch with instant On, and
one-minute Off delay
fi Volume control
Dimensions (HxWxD) 16
1
¼
8
x 15
3
¼
4
x 16
1
¼
8
"
41cm x 40cm x 41cm
Weight 57 lbs (26kg)
Finish Hand-sanded, hand-painted
Black on American Oak veneer
INTRODUCTION
We designed the PS.10 for maximum output in an
incredibly compact enclosure. With bass extension
to 27Hz (-6dB) and output over 105dB at a typical
listening position in a 3,000 cubic-foot room, the
PS.10 meets the demands of digital 5.1 formats.
Yet, the PS.10 is so compact, it easily fits within a
typical AV cabinet.
Tuned for Flexibility
We tuned the PS.10 to match the speed and sonic
presentation of the Snell E.5 Tower and K.5
Monitor. We included a system-specific electronic
crossover that automatically adjusts the output of
your front speakers, so you are assured of a seam-
less blend between the PS.10 and your E.5 or K.5
speaker systems.
Plus, we incorporated a number of user-definable
settings, giving you the flexibility to fine-tune the
PS.10 to match your existing system.
Easy to Hide
The PS.10 cabinet is small enough to tuck behind
furniture or place in a closet. Because the bass unit
and ports are on the front of the cabinet, you can
place the PS.10 directly inside a typical AV cabinet
system without performance degradation.
