INTRODUCTION
We designed the SR.5 for maximum placement flexibility.
You can mount the SR.5’s virtually anywhere around your
listening room and still achieve strong envelopment. The
SR.5’s use a unique bipolar radiating pattern for dozens
of unique placement options.
fi On side walls
fi On back walls
fi On the ceiling
Most importantly, the SR.5’s do not require symmetrical
placement. You can place one unit on a side wall, and the
other on the ceiling or back wall.
For Use With All Home Theater Formats
The SR.5’s meet the demanding sonic requirements of
digital 5.1 formats.
fi Their dispersion pattern combines an
optimal blend of diffuse sound, with just
enough directivity for precise off-screen pans.
fi They extend from 70 to 20,000Hz, capturing all
surround information in this range.
fi They play loud enough to fill a typical
listening room at theater volume.
fi Their power response matches the Snell K.5
Monitors and E.5 Towers for seamless front-to-
back pans.
SPECIFICATIONS
Specifications SR.5 Surround
Usable Frequency Range 70–20,000Hz
Power Response (±3dB) 90–12,000Hz
Recommended Amplifier Power 20–150 watts
Nominal Impedance 8 ohms
Sensitivity 90dB [1 watt (2.83v) at 1m]
speaker in half space, wall-mounted
High Frequency Drivers Dual subenclosed 3 1¼2" (89mm) extended-range units
with copolymer cones
Bass Unit 5 1¼4" (135mm) omnidirectional unit with cast-alu-
minum basket, copolymer cone, and butyl rubber surround
Crossover Frequency 400Hz
Cabinet Construction High density fiberboard
Grilles Friction fit cloth grilles on an MDF frame
Flush Mounting Bracket Positive-click locking mounting bracket for wall or ceiling
Included Hardware Four (4) 3" #10 machine screws with toggle wings
Four (4) 2" #8 particleboard screws
Eight (8) felt bumpers
Dimensions (HxWxD) 13.75" x 6.75" x 7.5" (343mm x 168mm x 187mm)
Weight/each 12 lbs. (5.5kg)
Finish Hand-sanded, hand-painted Black or White paint
