Options – 12 S2646/S3246
Upper Control Box with Horn and Battery Condition Indicator
0371952 1 UPPER CONTROL BOX WITH HORN
1 0072545 1 DECAL EMERGENCY STOP
2 0361213 1 ASSY UPPER CONTROL BOX
3 0361449 1 JOYSTICK
4 0371912 1 PLAC UPPER CONTROL BOX 3246
5 446826 1 SW CONTACT BLOCK N.C.
6 446836 1 OPERATOR PUSH/PULL 2-POSITION
7 3020013 1 SW TGL SPST (ON/OFF) SEALED
8 3020097 1 SW TGL DPDT(ON/ON) SEALED
9 3049862 1 RECEPTACLE
9A 3040208 1 PANEL NUT
9B 3040209 1 WASHER LOCK
10 5560080 1 BUMPER ADHESIVE BACK
11 3026027 1 SW PUSH BUTTON
12 0071269 1 DECAL HORN
13 3040411 1 ALARM MINI SIREN
14 487696 1 BATTERY GAUGE
Following items not shown, inside of control box
0361227 1 UPPER CONTROL BOX INTERNAL HARNESS
0361299 2 ADAPTER HARNESS
0361314 1 HORN JUMPER WIRE
3043813 2 CONN AMP PLUG
0361315 1 BATT COND JUMPER WIRE
Item Part No. Qty. Description
