144
Model: Snorkel SR9244 SR1054
Part Number: 159-0037-000
Snorkel International, LLC
2009 Roseport Road
Elwood, KS 66024
LUBRICANT/LIQUID CHARACTERISTICS 5.26
ENGINE OIL 5.26.1
Only use lubricants with the following technical characteristics:
DQC IV LA - ACEA E6 / API CJ-4 / JASO DH-2SAE.
The recommended viscosity is: SAE 5W-30.
The total capacity of the circuit is 8 litres.
HYDRAULIC SYSTEM OIL 5.26.2
Use hydraulic oil with the following specifications:
• OIL HV ISO 46
Performance levels:
ISO 6743-4 HV, Afnor NFE 48-062, ISO 11158, DIN 51524 Part 3 HVLP, Afnor NFE 48-603 HV, ASTM D6158,
Denison HF-0 / HF-1 / HF-2, Eaton Vickers I-286-S / M-2950-S, Cincinnati Machine P-68 / P-69 / P-70, Afnor
NFE 48-690(dry), Afnor NFE 48-691(wet), U.S. Steel 126 / 127 / 136, JCMAS HK, Bosch variable vane pumps,
Rexroth RE 90220, Sauer Danfoss 520L0463, General Motors (LS-2) LH-03-1 / LH-04-1 / LH-06-1, SEB 81222.
Amount of oil required in the system 150 litres.
AXLE OIL 5.26.3
Do not use synthetic or vegetable oil. Use oils with the following technical specifications:
• SAE 85W90 LS / API GL 4/ MIL L 2105.
Amount of oil in the differential: 10 litres.
Amount of oil in the planetary reduction gear (on each side): 0.6 litres.
TB172 GEAR BOX OIL 5.26.4
Do not use synthetic or vegetable oil. Use oils with the following technical specifications:
SAE 80W90 / API GL 4-GL5/ MIL L 2105 - 2015-B
Amount of oil in the gearbox: 0.5 litres.
