TB42J – 0172310
3
Chapter 2 – Specifications
Component Identification
Right Side
Chassis
Lower
Controls
Upper Controls
Drive Wheels
(T
wo-Wheel Drive)
Fuel T
ank
S
teer Wheels
Left Side
Platform
Main Boom
Tip Boom
Hydraulic Fluid T
ank
And Filter
Battery Disconnect
Switch
Batteries
Engine
S
teer Wheels
Drive Wheels
(T
wo-Wheel Drive)
Platform
Foot Switch
Operator’s
Manual
Emergency
Lowering V
alve
Jib
6
8
