Chapter 2 – Specifications
4 TB42J – 0172310
Working Envelope
50°
18°
Feet
(Meters)
0
20
(6.1)
10
(3.0)
30
(9.1)
40
(12.2)
0
10
(3.0)
20
(6.1)
30
(9.1)
40
(12.2)
50
(15.2)
10
(3.0)
75°
70°
70°
10
(3.0)
