Snorkel TB42J User Manual

Chapter 2 – Specifications
TB42J – 0172310 5
General Specifications
Aerial Platform
Working height 47′ 6″ (14.5 m)
Maximum platform height 41′ 6″ (12.6 m)
Horizontal reach 34′ 9″ (10.59 m)
Main boom
Articulation -18° to +75°
Extension 12′ (3.6 m)
Turntable rotation 360° continuous
Turning radius, inside 5′ 2″ (1.6 m)
Wheelbase 8′ (2.4 m)
Ground clearance 10″ (25 cm)
Maximum wheel load 6,200 lbs (2812 kg)
Maximum ground pressure 61 psi (4.3 kg/cm²)
Weight, GVW
Approximate 11,990 lbs (5,439 kg)
Stowed width 7′11.5″ (2.4 m)
Stowed length 29′ 5″ (9 m)
Stowed length, tucked stow 23′ 9″ (7.2 m)
Stowed height 7′ 6″ (2.3 m)
Stowed height, tucked stow 8′ 1″ (2.5 m)
Platform
Dimensions
Standard Steel 30″ x 60″ (76 cm x 152 cm)
Optional Aluminum 30″ x 60″ (76 cm x 152 cm)
Optional Aluminum 30″ x 92″ (76 cm x 244 cm)
Rated work load
Steel 30″ x 60″ 500 lb (227 kg)
Aluminum 30″ x 60″ 600 lb (272 kg)
Aluminum 30″ x 92″ 500 lb (227 kg)
Rotation 90° CW to 80° CCW
Maximum number of occupants 2 people
Optional AC generator 110 V, 2,000 watt, 60 Hz
Optional AC generator 220 V, 2,000 watt, 50 Hz
Function Speed
Turntable rotation 60 to 65 seconds
Main boom
Up 35 to 45 seconds
Down 40 to 45 seconds
Extend 35 to 45 seconds
Retract 25 to 35 seconds
Jib
Up 25 to 35 seconds
Down 25 to 35 seconds
Platform rotation 8 to 15 seconds
Drive
High, booms stowed 3.0 mph (4.8 km/h)
Low, booms elevated 1.0 mph (1.6 km/h)
Drive System
Standard Two-wheel drive
Optional Four-wheel drive
Gradeability 25%
Tires, 10 ply
Pneumatic 12″ x 16.5″ (30 cm x 42 cm)
Foam filled 12″ x 16.5″ (30 cm x 42 cm)
Flotation 15″ x 19.5″ (38 cm x 50 cm)
Electrical System
Voltage 12 V DC negative chassis ground
Source
Gas engine One -12 V 600 CCA battery
Diesel engine Two - 12 V 600 CCA batteries
Fluid recommended distilled water
Hydraulic System
Maximum pressure 3,000 psi (20,684 kPa)
Reservoir capacity 16.5 US gal (62.4 l)
System capacity 20 US gal (75.7 l)
Maximum operating temperature 200°F (93°C)
Hydraulic fluid recommended
Above 10°F (-13°C) Mobil DTE-13M
(ISO VG32)
Below 10°F (-13°C) Mobil DTE-11M
(ISO VG15)
Engine
Diesel Cummins B3.3
Diesel Deutz F3L-2011F
Fuel Tank Capacity
Diesel 20 US gal (75.7 l)
Ambient Air Temperature Operating Range
Fahrenheit 0°F to 110°F
Celsius -18°C to 43°C
Maximum Wind Speed
Gust or steady 28 mph (45 km/h)
