Snorkel TM12 Service And Parts Manual

Operation Manual Page 14
Specifications
S PECIFICATIONS
*Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
Refer to the Service Manual for complete parts and service information.
This machine meets or exceeds all applicable CE and GS machinery directive requirements.
ITEM TM12
Platform Size 73,7 cm x 1,04 m (29 in. x 41 in.)
Maximum Platform Capacity 227 kg (500 lbs.)
Maximum Number of Occupants 2 People indoors/1 person outdoors
Height
Working Height
5,83 m (19 ft.)
Maximum Platform Height
3,83 m (12.5 ft.)
Minimum Platform Height
48,3 cm (19 in.)
Dimensions
Weight
776 kg (1710 lbs.)
Overall Width
76 cm (30 in.)
Overall Height
165 cm (65 in.)
Overall Length
1,36 m (53.5 in.)
Drive Speed
Platform Lowered
3,65 km/h (2.27 mph)
Platform Raised
0,87 km/h (0.54 mph)
Energy Source 24V battery pack
Four 220 ampere hour, 6 Volt batteries, min. wt. 26,3 kg (58 lbs.) each
4 HP DC electric motor
System Voltage 24 VDC
Battery Charger 20 AMP, 220 V AC 50Hz
Battery Duty Cycle 25% for 8 Hours
Hydraulic Reservoir Capacity 7,2 L (1.9 gal)
Maximum Hydraulic System Pressure 165 bar (2400 psi)
Hydraulic Fluid
Normal above 32° F [0° C]
ISO #46
Low Temp. below 32° F [0° C]
ISO #32
below 0° F [-17° C]
ISO #15
Lift System One Single Stage Lift Cylinder
Drive Control Proportional
Control System
Proportional Control Handle with Interlock, Selector Switch,
Red Mushroom Emergency Stop Switches
Horizontal Drive Dual Front Wheel
Tires 30,5 cm (12 in.) diameter solid rubber, Non-marking
Parking Brakes Dual, Spring Applied, Hydraulic Release
Turning Radius 37 cm (14.5 in.) Inside
Maximum Gradeability 14º (25%)
Wheel Base 97,8 cm (38.5 in.)
Guardrails 1,10 m (43 in.)
Toeboard 152 mm (6 in.)
Noise Level

Snorkel TM12 Specifications

General

Brand	Snorkel
Model	TM12
Category	Lifting Systems
Language	English
