Socla Sylax User Manual

Technical manual Sylax DN 25-350 mm
uksylax25_350 - Updated 20/09/201610
Pressure
DIRECTIVE 2014/68/UE Equipments under pressure.
Products manufactured in conformity with the requirements of the directive, according to pressure, DN
and fluid (see on the precedent page )
.
PS : Maximum allowable pressure (in bar) according to Directive 2014/68/UE
PFA : Allowable operating pressure (in bar) for supply, distribution and disposal of water.
LINERS
DN mm Cat.
MOUNTING
PFA
PS
L1 L2 G1 G2
6 bar
EPDM, Nitrile (CC333G disc), White
EPDM
32 to 150
3.3
Flanges
6 6 6 6
End of line
4 4 4 4
200 to 350
I
Flanges
6 6 6 6
End of line
4 4 4 4
Nitrile (except CC333G disc),
Neoprene, Butyl, Hypalon, Natural
rubber, White natural rubber.
32 to 100
I
Flanges
6 6 6 6 6
End of line
4 4 4 4
125 to 350
II
Flanges
6 6 6 6 6
End of line
4 4 4 4
10 bar
EPDM, Nitrile (CC333G disc), White
Nitrile, Carboxylated Nitrile , White
EPDM
25 to 100
3,3
Flanges
10 10 10 10
End of line
6 6 6 6
125 & 150
I
Flanges
10 10 10 10
End of line
6 6 6 6
200 to 350
I
Flanges
10 10 10 10
End of line
6 6 6 6
Nitrile (except CC333G disc),
FKM
25
3,3
Flanges
10 10 10 10 10
End of line
6 6 6 6
32 to 100
I
Flanges
10 10 10 10 10
End of line
6 6 6 6
125 to 350
II
Flanges
10 10 10 10 10
End of line
6 6 6 6
Silicone
32 to 100
I
Flanges
10 10 10 10 10
End of line
6 6 6 6
125 to 150
II
Flanges
10 10 10 10 10
End of line
6 6 6 6
200 to 350
II
Flanges
6 6 6 6 6
End of line
4 4 4 4
16 bar
EPDM, Nitrile (CC333G disc)
32 to 100
3,3
Flanges
16 16 16 10
End of line
12 12 12 10
125
I
Flanges
16 16 16 10
End of line
12 12 12 10
150
I
Flanges
16 10 16 10
End of line
12 6 12 10
200 to 300
I
Flanges
16 10 16 10
End of line
10 6 10 10
350
I
Flanges
16 10 16 10
End of line
8 6 8 8
Nitrile (except CC333G disc),
Neoprene, Butyl, Hypalon, Natural
rubber, White natural rubber
32 to 100
I
Flanges
16 16 16 10 16
End of line
12 12 12 12
125 & 150
II
Flanges
16 16 16 10 16
End of line
12 12 12 12
200 to 300
II
Flanges
16 16 16 10 10
End of line
10 10 10 10
350
II
Flanges
16 16 16 10 10
End of line
8 8 8 8
20 bar
EPDM, Nitrile (CC333G disc)
32 to 250
3,3
Flanges
20 20
End of line
12 12
300 & 350
I
Flanges
20 20
End of line
12 12
Nitrile (except CC333G disc), Neo-
prene, Butyl, Natural rubber, White
natural rubber
32 to 100
3,3
Flanges
20 20 20
End of line
12 12 12
125 to 350
II
Flanges
20 20 20
End of line
12 12 12
25 bar
EPDM, Nitrile (CC333G disc)
32 to 150
3,3
Flanges
25 25
End of line
16 16
Nitrile (except CC333G disc)
32 to 80
3,3
Flanges
25 25 25
End of line
16 16 16
100 to 150
II
Flanges
25 25 25
End of line
16 16 16
ATTENTION
Gas G1 and G2 : The max.
pressure is 6 bar when
using cast iron 5.1301(EN-
GJL-250).
NOTE : Butterfly valves of
category II used as «end
of line», please consult us.
